Machine Id: 1339 Serial No:
Model: ZSA 320 Asking Price: onrequest
Make: Hurth Country: Germany
Year: Weight: 0.0
Dimensions: Location: Mumbai Warehouse,India
Power:
Category: Gear Related Machines
Type of Machine: Gear Shavers
Specification

Max.Gear Diameter : 320 mm
Module - 8
Feed - 6 - 285 mm/min
Shaving Cutter Diameter - 174 - 260 mm
Shaving Cutter Drive Motor 3KW
Shaving Wheel Spindle Turning Speeds - 45 - 385 U/min
Table Travel Cross - 10mm
Table Travel Longitudinal - 150mm
Tooth Width - 150mm
Total Power Requirement - 12 kW
Vertical Adjustment Of Table - 175mm
Weight - 5500 Kg

Description
