Specifications :-
Testing Capabilities for Bevel & Hypoid Gears:
Rolling Qualities
Tooth Spacing
Tooth Profile
Concentricity
Backlash
Runout
SPINDLE RUNOUT:
Drive Spindle Bore:
Drive Spindle Face:
Driven Spindle Bore:
Driven Spindle Face:

SPECIFICATIONS:
Max. Diameter Of Gears: 7-1/2"
Range Of Angles: 0 Deg. - 180 Deg.
Range Of Pinion Spindle Offset Above/Below Center: 1-1/4"
Distance From Center Of Pinion Spindle:
To Nose Of Gear Spindle: 7"Max; 0"Min
Distance From Center Of Gear Spindle:
To Nose Of Pinion Spindle: 7"Max; 1"Min
Drive Spindle Speed (900 & 1800 RPM Motor): 1750 RPM & 3500 RPM
Diameter Of Taper Hole, Large End: 1-51/64"
Taper Per Foot: 1/2"
Depth Of Taper: 3"
Diameter Of Hole Through Spindle: 1-5/16"
Net Weight: 2100 lbs

Already rebuilt and certified — ready for immediate use.

As-good-as-new accuracy, restored to Gleason standards.

Modern reliability with DRO, renewed electricals, and fresh bearings.

Proven expertise: Over 40 years of gear industry experience.

Worldwide delivery & references available for overseas clients.
