Swing 36INCHES, Grinding Stroke 13INCHES

  2. Category List
  3. Internal Bore Grinders With Faceing W/o Faceing (Conventional & Cnc)
  4. 172

Internal Bore Grinders With Faceing W/o Faceing (Conventional & Cnc)

Add this Favourite
Download Product PDF Enquiry / Quote / Interested For Agents Download Pics Download Photo / Zip

Enlargeable Images :

Video
Machine Id: 177 Serial No:
Model: 172 Asking Price: onrequest
Make: heald Country: United States
Year: Weight: 0.0
Dimensions: Location: Mumbai WareHouse, India
Power:
Category: Internal Bore Grinders With Faceing W/o Faceing (Conventional & Cnc)
Type of Machine: bore grinder
Specification

Model Heald-172
Swing 36INCHES
Maximum Diameter Of Hole That Can Be Ground 14INCHES
Hole Length Maximum 11INCHES
Table Speeds 0 TO 18 FPM
Work Head Speeds (4) 70 TO 210 RPM
Grinding Stroke 13INCHES
Gap Adjustment 6-1/4INCHES TO 13-1/2INCHES
Red Head Spindle Speeds 4500 RPM

Description

There are two spindles with the machine one which is mounted on the machine and second one which is a spare one.
EXCELLENT CONDITION
