Machine Id: 1156 Serial No: 10050830
Model: H 250 D2 Asking Price: onrequest
Make: Buhler Country: Switzerland
Year: Weight: 0.0
Dimensions: Location: Mumbai Warehouse,India
Category: Pressure Die Casting Machines (PDC)
Type of Machine: pressure die casting machines

250 ton locking force, with Buhler Direct injection with parashot


Central Dieheight adjument, Central Lubrication etc.


Excellent condition. Full guarding, Intercirc Control


Locking force 250 tonnes, Injection force adjustable (with itensifier) 35 tonnes

Hydraulic ejection force 15 tonnes, Die mounting plates H x V mm 800 x 850

Space between tie bars H x V mm 500 x 550, Tie bar diameter 100mm

Max die height 750mm, Min die height 225mm

Die opening stroke 500mm

injection plunger stroke 350mm

Ejector stroke adjustable 100mm

Free cycle time 4.5sec

Motor capacity 22.4kw

Machine area 5900 x 1600 mm,

Capacity of oil tank 550 litres
