Max.Gear Diameter : 320 mm
Module - 8
Feed - 6 - 285 mm/min
Shaving Cutter Diameter - 174 - 260 mm
Shaving Cutter Drive Motor 3KW
Shaving Wheel Spindle Turning Speeds - 45 - 385 U/min
Table Travel Cross - 10mm
Table Travel Longitudinal - 150mm
Tooth Width - 150mm
Total Power Requirement - 12 kW
Vertical Adjustment Of Table - 175mm
Weight - 5500 Kg
