CNC Lathes

Download Product PDF Enquiry / Quote / Interested Add this Favourite For Agents Download Pics

Enlargeable Images :

Download Photo / Zip
Video
Machine Id: 1110 Serial No:
Model: 3000 Asking Price: onrequest
Make: Colchester Country: United Kingdom
Year: Weight: 0.0
Dimensions: Location:
Power:
Category: CNC Lathes
Type of Machine: CNC Lathe
Specification
Distance between centers1000 mm
Height of centers215 mm
tailstock center sleeve diameter74,6 mm
Stroke of the sleeve230 mm
max. admitted diameter over the bed433 mm
Maximum swing over cross-slide267 mm
Hole through spindle76 mm
Width of the bed343 mm
Spindle speed20 - 1600 RPM
Maximum swing in gap711 mm
Spindle noseCamlock D1 8"
Spindle taperCM 5
Spindle motor9.3 KW
Dimensions2700 x 2000 x 1800 mm
Approximate weight (Kg)2650 kgs
Description
